* Copyright (C) 2013 The Android Open Source Project
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* http://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
package com.example.android.bluetoothlegatt;
import android.app.Service;
import android.bluetooth.BluetoothAdapter;
import android.bluetooth.BluetoothDevice;
import android.bluetooth.BluetoothGatt;
import android.bluetooth.BluetoothGattCallback;
import android.bluetooth.BluetoothGattCharacteristic;
import android.bluetooth.BluetoothGattDescriptor;
import android.bluetooth.BluetoothGattService;
import android.bluetooth.BluetoothManager;
import android.bluetooth.BluetoothProfile;
import android.content.Context;
import android.content.Intent;
import android.os.Binder;
import android.os.IBinder;
import android.util.Log;
import java.util.List;
import java.util.UUID;
/**
* Service for managing connection and data communication with a GATT server hosted on a
* given Bluetooth LE device.
*/
public class BluetoothLeService extends Service {
private final static String TAG = BluetoothLeService.class.getSimpleName();
private BluetoothManager mBluetoothManager;
private BluetoothAdapter mBluetoothAdapter;
private String mBluetoothDeviceAddress;
private BluetoothGatt mBluetoothGatt;
private int mConnectionState = STATE_DISCONNECTED;
private static final int STATE_DISCONNECTED = 0;
private static final int STATE_CONNECTING = 1;
private static final int STATE_CONNECTED = 2;
public final static String ACTION_GATT_CONNECTED =
"com.example.bluetooth.le.ACTION_GATT_CONNECTED";
public final static String ACTION_GATT_DISCONNECTED =
"com.example.bluetooth.le.ACTION_GATT_DISCONNECTED";
public final static String ACTION_GATT_SERVICES_DISCOVERED =
"com.example.bluetooth.le.ACTION_GATT_SERVICES_DISCOVERED";
public final static String ACTION_DATA_AVAILABLE =
"com.example.bluetooth.le.ACTION_DATA_AVAILABLE";
public final static String EXTRA_DATA =
"com.example.bluetooth.le.EXTRA_DATA";
public final static UUID UUID_HEART_RATE_MEASUREMENT =
UUID.fromString(SampleGattAttributes.HEART_RATE_MEASUREMENT);
// Implements callback methods for GATT events that the app cares about. For example,
// connection change and services discovered.
private final BluetoothGattCallback mGattCallback = new BluetoothGattCallback() {
@Override
public void onConnectionStateChange(BluetoothGatt gatt, int status, int newState) {
String intentAction;
if (newState == BluetoothProfile.STATE_CONNECTED) {
intentAction = ACTION_GATT_CONNECTED;
mConnectionState = STATE_CONNECTED;
broadcastUpdate(intentAction);
Log.i(TAG, "Connected to GATT server.");
// Attempts to discover services after successful connection.
Log.i(TAG, "Attempting to start service discovery:"
mBluetoothGatt.discoverServices());
} else if (newState == BluetoothProfile.STATE_DISCONNECTED) {
intentAction = ACTION_GATT_DISCONNECTED;
mConnectionState = STATE_DISCONNECTED;
Log.i(TAG, "Disconnected from GATT server.");
broadcastUpdate(intentAction);
}
}
@Override
public void onServicesDiscovered(BluetoothGatt gatt, int status) {
if (status == BluetoothGatt.GATT_SUCCESS) {
broadcastUpdate(ACTION_GATT_SERVICES_DISCOVERED);
} else {
Log.w(TAG, "onServicesDiscovered received: " status);
}
}
@Override
public void onCharacteristicRead(BluetoothGatt gatt,
BluetoothGattCharacteristic characteristic,
int status) {
if (status == BluetoothGatt.GATT_SUCCESS) {
broadcastUpdate(ACTION_DATA_AVAILABLE, characteristic);
}
}
@Override
public void onCharacteristicChanged(BluetoothGatt gatt,
BluetoothGattCharacteristic characteristic) {
broadcastUpdate(ACTION_DATA_AVAILABLE, characteristic);
}
};
private void broadcastUpdate(final String action) {
final Intent intent = new Intent(action);
sendBroadcast(intent);
}
private void broadcastUpdate(final String action,
final BluetoothGattCharacteristic characteristic) {
final Intent intent = new Intent(action);
// This is special handling for the Heart Rate Measurement profile. Data parsing is
// carried out as per profile specifications:
// http://developer.bluetooth.org/gatt/characteristics/Pages/CharacteristicViewer.aspx?u=org.bluetooth.characteristic.heart_rate_measurement.xml
if (UUID_HEART_RATE_MEASUREMENT.equals(characteristic.getUuid())) {
int flag = characteristic.getProperties();
int format = -1;
if ((flag & 0x01) != 0) {
format = BluetoothGattCharacteristic.FORMAT_UINT16;
Log.d(TAG, "Heart rate format UINT16.");
} else {
format = BluetoothGattCharacteristic.FORMAT_UINT8;
Log.d(TAG, "Heart rate format UINT8.");
}
final int heartRate = characteristic.getIntValue(format, 1);
Log.d(TAG, String.format("Received heart rate: %d", heartRate));
intent.putExtra(EXTRA_DATA, String.valueOf(heartRate));
} else {
// For all other profiles, writes the data formatted in HEX.
final byte[] data = characteristic.getValue();
if (data != null && data.length > 0) {
final StringBuilder stringBuilder = new StringBuilder(data.length);
for(byte byteChar : data)
stringBuilder.append(String.format("%02X ", byteChar));
intent.putExtra(EXTRA_DATA, new String(data) "\n" stringBuilder.toString());
}
}
sendBroadcast(intent);
}
public class LocalBinder extends Binder {
BluetoothLeService getService() {
return BluetoothLeService.this;
}
}
@Override
public IBinder onBind(Intent intent) {
return mBinder;
}
@Override
public boolean onUnbind(Intent intent) {
// After using a given device, you should make sure that BluetoothGatt.close() is called
// such that resources are cleaned up properly. In this particular example, close() is
// invoked when the UI is disconnected from the Service.
close();
return super.onUnbind(intent);
}
private final IBinder mBinder = new LocalBinder();
/**
* Initializes a reference to the local Bluetooth adapter.
*
* @return Return true if the initialization is successful.
*/
public boolean initialize() {
// For API level 18 and above, get a reference to BluetoothAdapter through
// BluetoothManager.
if (mBluetoothManager == null) {
mBluetoothManager = (BluetoothManager) getSystemService(Context.BLUETOOTH_SERVICE);
if (mBluetoothManager == null) {
Log.e(TAG, "Unable to initialize BluetoothManager.");
return false;
}
}
mBluetoothAdapter = mBluetoothManager.getAdapter();
if (mBluetoothAdapter == null) {
Log.e(TAG, "Unable to obtain a BluetoothAdapter.");
return false;
}
return true;
}
/**
* Connects to the GATT server hosted on the Bluetooth LE device.
*
* @param address The device address of the destination device.
*
* @return Return true if the connection is initiated successfully. The connection result
* is reported asynchronously through the
* {@code BluetoothGattCallback#onConnectionStateChange(android.bluetooth.BluetoothGatt, int, int)}
* callback.
*/
public boolean connect(final String address) {
if (mBluetoothAdapter == null || address == null) {
Log.w(TAG, "BluetoothAdapter not initialized or unspecified address.");
return false;
}
// Previously connected device. Try to reconnect.
if (mBluetoothDeviceAddress != null && address.equals(mBluetoothDeviceAddress)
&& mBluetoothGatt != null) {
Log.d(TAG, "Trying to use an existing mBluetoothGatt for connection.");
if (mBluetoothGatt.connect()) {
mConnectionState = STATE_CONNECTING;
return true;
} else {
return false;
}
}
final BluetoothDevice device = mBluetoothAdapter.getRemoteDevice(address);
if (device == null) {
Log.w(TAG, "Device not found. Unable to connect.");
return false;
}
// We want to directly connect to the device, so we are setting the autoConnect
// parameter to false.
mBluetoothGatt = device.connectGatt(this, false, mGattCallback);
Log.d(TAG, "Trying to create a new connection.");
mBluetoothDeviceAddress = address;
mConnectionState = STATE_CONNECTING;
return true;
}
/**
* Disconnects an existing connection or cancel a pending connection. The disconnection result
* is reported asynchronously through the
* {@code BluetoothGattCallback#onConnectionStateChange(android.bluetooth.BluetoothGatt, int, int)}
* callback.
*/
public void disconnect() {
if (mBluetoothAdapter == null || mBluetoothGatt == null) {
Log.w(TAG, "BluetoothAdapter not initialized");
return;
}
mBluetoothGatt.disconnect();
}
/**
* After using a given BLE device, the app must call this method to ensure resources are
* released properly.
*/
public void close() {
if (mBluetoothGatt == null) {
return;
}
mBluetoothGatt.close();
mBluetoothGatt = null;
}
/**
* Request a read on a given {@code BluetoothGattCharacteristic}. The read result is reported
* asynchronously through the {@code BluetoothGattCallback#onCharacteristicRead(android.bluetooth.BluetoothGatt, android.bluetooth.BluetoothGattCharacteristic, int)}
* callback.
*
* @param characteristic The characteristic to read from.
*/
public void readCharacteristic(BluetoothGattCharacteristic characteristic) {
if (mBluetoothAdapter == null || mBluetoothGatt == null) {
Log.w(TAG, "BluetoothAdapter not initialized");
return;
}
mBluetoothGatt.readCharacteristic(characteristic);
}
/**
* Enables or disables notification on a give characteristic.
*
* @param characteristic Characteristic to act on.
* @param enabled If true, enable notification. False otherwise.
*/
public void setCharacteristicNotification(BluetoothGattCharacteristic characteristic,
boolean enabled) {
if (mBluetoothAdapter == null || mBluetoothGatt == null) {
Log.w(TAG, "BluetoothAdapter not initialized");
return;
}
mBluetoothGatt.setCharacteristicNotification(characteristic, enabled);
// This is specific to Heart Rate Measurement.
if (UUID_HEART_RATE_MEASUREMENT.equals(characteristic.getUuid())) {
BluetoothGattDescriptor descriptor = characteristic.getDescriptor(
UUID.fromString(SampleGattAttributes.CLIENT_CHARACTERISTIC_CONFIG));
descriptor.setValue(BluetoothGattDescriptor.ENABLE_NOTIFICATION_VALUE);
mBluetoothGatt.writeDescriptor(descriptor);
}
}
/**
* Retrieves a list of supported GATT services on the connected device. This should be
* invoked only after {@code BluetoothGatt#discoverServices()} completes successfully.
*
* @return A {@code List} of supported services.
*/
public List<BluetoothGattService> getSupportedGattServices() {
if (mBluetoothGatt == null) return null;
return mBluetoothGatt.getServices();
}
}
资源文件列表
android-BluetoothLeGatt-master/.google/packaging.yaml , 523
android-BluetoothLeGatt-master/Application/build.gradle , 1404
android-BluetoothLeGatt-master/Application/src/main/AndroidManifest.xml , 2094
android-BluetoothLeGatt-master/Application/src/main/java/com/example/android/bluetoothlegatt/BluetoothLeService.java , 12924
android-BluetoothLeGatt-master/Application/src/main/java/com/example/android/bluetoothlegatt/DeviceControlActivity.java , 13736
android-BluetoothLeGatt-master/Application/src/main/java/com/example/android/bluetoothlegatt/DeviceScanActivity.java , 9263
android-BluetoothLeGatt-master/Application/src/main/java/com/example/android/bluetoothlegatt/SampleGattAttributes.java , 1688
android-BluetoothLeGatt-master/Application/src/main/res/drawable-hdpi/ic_launcher.png , 5170
android-BluetoothLeGatt-master/Application/src/main/res/drawable-hdpi/tile.9.png , 196
android-BluetoothLeGatt-master/Application/src/main/res/drawable-mdpi/ic_launcher.png , 3025
android-BluetoothLeGatt-master/Application/src/main/res/drawable-xhdpi/ic_launcher.png , 7227
android-BluetoothLeGatt-master/Application/src/main/res/drawable-xxhdpi/ic_launcher.png , 12800
android-BluetoothLeGatt-master/Application/src/main/res/layout/actionbar_indeterminate_progress.xml , 942
android-BluetoothLeGatt-master/Application/src/main/res/layout/gatt_services_characteristics.xml , 3389
android-BluetoothLeGatt-master/Application/src/main/res/layout/listitem_device.xml , 1266
android-BluetoothLeGatt-master/Application/src/main/res/menu/gatt_services.xml , 1265
android-BluetoothLeGatt-master/Application/src/main/res/menu/main.xml , 1247
android-BluetoothLeGatt-master/Application/src/main/res/values-sw600dp/template-dimens.xml , 802
android-BluetoothLeGatt-master/Application/src/main/res/values-sw600dp/template-styles.xml , 876
android-BluetoothLeGatt-master/Application/src/main/res/values-v11/template-styles.xml , 726
android-BluetoothLeGatt-master/Application/src/main/res/values-v21/base-colors.xml , 658
android-BluetoothLeGatt-master/Application/src/main/res/values-v21/base-template-styles.xml , 768
android-BluetoothLeGatt-master/Application/src/main/res/values/base-strings.xml , 985
android-BluetoothLeGatt-master/Application/src/main/res/values/strings.xml , 1614
android-BluetoothLeGatt-master/Application/src/main/res/values/template-dimens.xml , 1107
android-BluetoothLeGatt-master/Application/src/main/res/values/template-styles.xml , 1363
android-BluetoothLeGatt-master/CONTRIB.md , 1612
android-BluetoothLeGatt-master/CONTRIBUTING.md , 1567
android-BluetoothLeGatt-master/LICENSE , 11340
android-BluetoothLeGatt-master/README.md , 234
android-BluetoothLeGatt-master/build.gradle , 10
android-BluetoothLeGatt-master/gradle/wrapper/gradle-wrapper.jar , 49896
android-BluetoothLeGatt-master/gradle/wrapper/gradle-wrapper.properties , 229
android-BluetoothLeGatt-master/gradlew , 5080
android-BluetoothLeGatt-master/gradlew.bat , 2404
android-BluetoothLeGatt-master/packaging.yaml , 496
android-BluetoothLeGatt-master/screenshots/1-main.png , 68389
android-BluetoothLeGatt-master/screenshots/2-detail.png , 80086
android-BluetoothLeGatt-master/screenshots/icon-web.png , 70614
android-BluetoothLeGatt-master/settings.gradle , 22
